P. 17
Solutions Anwendungen
Conclusion
The airport deployments described here
represent some of the most demanding
conditions for a BACnet-integrated wireless
sensor network. The outcome is consistent
across building types, geographies, and
application domains: battery-free wireless
sensors, connected via open-standard gateways
into a BACnet backbone, deliver the flexibility and
reduced lifecycle cost that large infrastructure
requires. The maintenance burden stays flat as
sensor counts grow; the ability to extend and
reconfigure the system remains intact across
Amsterdam Airport Schiphol uses wireless sensors for PRM wheelchair tracking (Source EnOcean GmbH) long operational lifetimes.
Der Flughafen Amsterdam Schiphol setzt drahtlose Sensoren zur Ortung von Rollstühlen für Personen mit
eingeschränkter Mobilität (PRM) ein (Quelle: EnOcean GmbH) © iStock
For BACnet system designers working on
airports, campuses, or any large-scale project,
Similar applications are running at Haneda (Tokyo Wireless commissioning lets sensors be the operational case is now well evidenced in the
Airport) Innovation City, where battery-free IoT added or relocated as buildings expand or field.
sensors have been installed across a campus operational needs change, without revisiting
covering restroom management, workstation the BACnet network design.
occupancy, parking, and environmental nd the open gateway model means new Die Skalierungsherausforderung in
A
monitoring. At major UK airports, the same sensor application domains can connect to an BACnet-Netzwerken auf Flughäfen
model is now being applied to infrastructure existing BACnet infrastructure incrementally,
protection. Water leak detection is one area without redesigning the system that already Flughäfen sind rund um die Uhr in Betrieb,
where battery-free sensing offers coverage that handles HVAC and lighting. umfassen sich ständig verändernde Gebäude-
would be difficult and costly to achieve with und Flächenstrukturen und erlauben während
conventional cabling. Emerging Airport Opportunities: Asset des laufenden Betriebs nur sehr eingeschränkte
Tracking Änderungen an der Infrastruktur. Ein Sensor-
The pattern is consistent: a BACnet infrastructure netzwerk, das regelmäßige Batteriewechsel
deployed for HVAC and lighting can, with the Beyond environmental sensing, airport operators oder Änderungen an der Verkabelung erfordert,
same wireless sensor layer, support additional are beginning to apply wireless sensor networks stellt bei dieser Größenordnung einen erhebli-
facility services without a separate network. to asset tracking, an approach that illustrates chen Wartungsaufwand dar – mit Kosten, die
the scalability of this approach in operationally sich vervielfachen, sobald die Anzahl der Daten-
Open Standards and BACnet Gateway complex environments. punkte in die Tausende geht.
Integration
Amsterdam Airport Schiphol, which handled Erfahrungen aus Projekten in Europa und Asien
The wireless sensors in these deployments nearly 67 million passengers in 2024, has zeigen, dass batterielose Funksensoren, die
communicate via the EnOcean standard, deployed a real-time asset tracking solution über Gateways auf Basis offener Standards in
published as ISO/IEC 14543-3-10/11 and for Passengers with Reduced Mobility (PRM) BACnet-Architekturen integriert werden, eine
designed specifically for building automation. services. Managing wheelchairs, caddies, praxisnahe Lösung für diese Herausforderung
Connection to a BACnet system is handled by and other specialist equipment across a darstellen.
gateways or bridges available from multiple large terminal requires accurate knowledge
suppliers, translating between the wireless of equipment location, buffer levels by zone, The Squaire am Flughafen Frankfurt:
protocol and BACnet objects. Because both and the ability to demonstrate service quality BACnet und Funktechnik im Großmaßstab
the wireless standard and BACnet are open, to airport stakeholders. The wireless sensor
the integration is multi-vendor at every layer. solution meets these requirements across the The Squaire ist ein 660 Meter langes, gemischt
System designers are not locked into a single full terminal footprint, including indoor and genutztes Gebäude, das direkt über dem Fern-
sensor manufacturer, gateway provider, or BMS semi-outdoor areas, without additional network bahnhof des Frankfurter Flughafens errich-
platform, and future additions to the sensor infrastructure. tet wurde. Es umfasst 140.000 Quadratmeter
network do not require vendor approval or auf neun Etagen und beherbergt zwei Hotels,
proprietary hardware. The application demonstrates a broader Büroflächen, Einzelhandel sowie ein Reisezen-
principle: the same open-standard wireless trum. Das Gesamtinvestitionsvolumen betrug
At airport scale, this architecture has three approach used for environmental sensing in rund 1,4 Milliarden Euro. Das Gebäude kombi-
practical consequences: HVAC and lighting control extends naturally to niert eine kabelgebundene Gebäudeautomation
B
attery-free operation removes a recurring operational logistics, using the same integration auf BACnet-Basis mit mehr als 16.000 batterie-
maintenance burden, particularly significant path into an existing BACnet infrastructure. losen Funkschaltern und -sensoren sowie über
when a sensor network runs to tens of 4.000 Empfängern und Gateways zur Steue-
thousands of points. rung von Beleuchtung und HLK-Anlagen (Hei-
